Genuine STK404-090 thick-film 50W×2 finished amplifier board – audiophile-grade stereo

Special note: This product is a finished board of stereo power amplifier, and no kit is provided for the time being.

The current shipment is green PCB board.

Note: Product pictures, videos, text and other related descriptions are all made by a certain period and are for reference only. If there is any change without notice, the specifics are mainly based on receipt of the actual product.

About Sanyo Semiconductor (ON Semiconductor member company)

Sanyo Semiconductor Co., Ltd. (a member company of ON Semiconductor) is a semiconductor manufacturing company with outstanding power supply device technologies, such as small package technology, energy-efficient switching technology, high-density packaging technology, etc., as well as world-class YI analog technology. Several analog-related assets include a wide range of process technology, analog design technology, skilled analog engineers, and specially designed and manufactured energy-saving and environmentally friendly devices, such as hybrid integrated circuits for inverters. Sanyo's core components include discrete circuits, general-purpose analog large-scale integrated circuits, ASSPs, and hybrid integrated circuits, which are widely used in a variety of products, such as personal computers, printers, cable TVs, mobile phones, audio-visual equipment, gaming equipment, car audio systems, and air conditioners.

Sanyo STK is commonly known as Sanyo Thick Film. Under the control of the tuned sound and high-precision semiconductor process production process, it is not the level that ordinary amateur DIY players can achieve. In addition to better sound field and resolution, the low-frequency strength is much stronger, which is completely the difference between professional athletes and ordinary players! These thick film circuits have always been customized products for big brand audio manufacturers. In the early days, many famous factories used them to manufacture power amplifiers, such as K + H, Sony Sony, Panasonic PANSONIC, KENWOOD, JEVIS JVC, Shanshui SANSUI, Sharp SHARP, Pioneer PIONEER, Aihua AIWA, etc. Almost all Japanese audio manufacturers use them, and they have been used for more than 20 years, which has influenced a whole generation. It is also a sound with a strong era brand that our entire generation heard when they were young. It always sounds unforgettable. Sanyo, a company specializing in the production of power amplifier modules, was later acquired by ON Semiconductor of the United States. After the acquisition, it integrated Sanyo's traditional craftsmanship, coupled with ON's unique design, and the later products were even more outstanding. They are still used by large companies in the United States, such as BOSE and Genelec in Europe!

Fortunately, I came across the power amplifier module STK404-090 produced by Sanyo SANYO in the later stage of the batch of new inventory. There are many models of this series, from STK404-050-140. This series of products is relatively late-stage production, using typical classic circuits, the circuit is relatively simple, the package is small, and the sound performance is good. The design output power is 50W @6 ohms, and the distortion is THD0.4%. Push the general bookshelf or floor-to-ceiling speakers to achieve satisfactory results. This thick film chip was only supplied to manufacturers that made the whole machine at that time, so it was difficult to see on the market.

This board is designed according to the concept of relatively fever, and all interfaces are solder-free and non-destructive to install. The materials used are carefully selected, and the power amplifier module can be installed horizontally or vertically. It is easier to use with a suitable radiator.(The filter capacitor of this board is a second-hand disassembly product, with a specification of 35V8100UF.)

    Sound performance: The overall tone is warm, the sound is relatively soft, the treble extension is high but not harsh, the bass is deep enough and elastic, and it will not be muddy without mixing. Sanyo thick film is a circuit between integrated and discrete power amplifiers. The fine workmanship and excellent craftsmanship are stronger than 3886 and 7294. Old players who have heard Aihua, SONY and other combined machines know that the sound is excellent, and it is difficult for general DIY players to achieve this level.

Power supply voltage: AC dual 22-35V (Greater than or less than this voltage cannot be used normally. When using AC greater than 24V, the filter capacitor needs to be replaced)

Output power: 50W@6 Ω

Accessories: three-core shielded input cable * 1,4P output cable * 1,15mm screw * 4

Circuit board size: 75 wide X142 long X43 high (excluding thick film chips)

   Weight: about 176g

The finished board is guaranteed for 3 months.

Power supply voltage: AC dual 22-35V (Greater than or less than this voltage cannot be used normally. When using AC greater than 24V, the filter capacitor needs to be replaced)

Output power: 100W 8Ω 150W 4Ω measured power

Accessories: three-core shielded input cable * 1,4P output cable * 1,15mm screw * 4

Circuit board size: 75 wide X142 long X43 high (excluding thick film chips)

The finished board is guaranteed for 3 months.

This finished board has a mono output, and two pieces are required for stereo use.

This product is very simple to use, the whole board has been tested, no need to debug, just add a transformer and radiator to make a sound, old power amplifier, speaker modification, measured power 150W4 ohm, easy to push large speakers, large speakers, the effect is much better than the general thousand yuan power amplifier, the real cost of small money to do big things.
